Sreaw Pin Shackle

Part No. Nominal Size  Working Load Limit Weight Dimensions Tolerance
mm + / -
inch t kg/pcs A B C D E F G H L M P C A
KSPAS0316 3/16 1/3 0.03 9.65 6.35 22.4 4.85 15.2 14.2 24.9 37.3 4.06 28.4 4.85 1.5 1.5
KSPAS0104 1/4 1/2 0.05 11.9 7.85 28.7 6.35 19.8 15.5 32.5 46.7 4.85 35.1 6.35 1.5 1.5
KSPAS0516 5/16 3/4 0.09 13.5 9.65 31 7.85 21.3 19.1 37.3 53 5.6 42.2 7.85 3.3 1.5
KSPAS0308 3/8 1 0.14 16.8 11.2 36.6 9.65 26.2 23.1 45.2 63 6.35 51.5 9.65 3.3 1.5
KSPAS0716 7/16 1-1/2 0.17 19.1 12.7 42.9 11.2 29.5 26.9 51.5 74 7.85 60.5 11.2 3.3 1.5
KSPAS0102 1/2 2 0.33 20.6 16 47.8 12.7 33.3 30.2 58.5 83.5 9.65 68.5 12.7 3.3 1.5
KSPAS0508 5/8 3-1/4 0.62 26.9 19.1 60.5 16 42.9 38.1 74.5 106 11.2 85 17.5 6.35 1.5
KSPAS0304 3/4 4-3/4 1.07 31.8 22.4 71.5 19.1 51 46 89 126 12.7 101 20.6 6.35 1.5
KSPAS0708 7/8 6-1/2 1.64 36.6 25.4 84 22.4 58 53 102 148 12.7 114 24.6 6.35 1.5
KSPAS0001 1 8-1/2 2.28 42.9 28.7 95.5 25.4 68.5 60.5 119 167 14.2 129 26.9 6.35 1.5
KSPAS0118 1-1/8 9-1/2 3.36 46 31.8 108 29.5 74 68.5 131 190 16 142 31.8 6.35 1.5
KSPAS0114 1-1/4 12 4.31 51.5 35.1 119 32.8 82.5 76 146 210 17.5 156 35.1 6.35 1.5
KSPAS0138 1-3/8 13-1/2 6.14 57 38.1 133 36.1 92 84 162 233 19.1 174 38.1 6.35 3.3
KSPAS0112 1-1/2 17 7.8 60.5 41.4 146 39.1 98.5 92 175 254 20.6 187 41.1 6.35 3.3
KSPAS0134 1-3/4 25 12.6 73 51 178 46.7 127 106 225 313 25.4 231 57 6.35 3.3
KSPAS0002 2 35 20.4 82.5 57 197 53 146 122 253 348 31 263 61 6.35 3.3
KSPAS0212 2-1/2 55 38.9 105 70 267 69 184 145 327 453 35.1 330 79.5 6.35 6.35
